1700V 3600A High Voltage IGBT Power Module
The HCGM3600E2SM17-TSA000 single switch IGBT module features advanced AISiC baseplate and AIN substrates, supporting 1700V and 3600A ratings. It delivers excellent thermal cycling and 10μs short-circuit withstand capability, making it ideal for traction drives, motor controllers, smart grids, and high-reliability inverters.
Description
Product Overview: The HCGM3600E2SM17-TSA000 single switch IGBT module utilizes cutting-edge AISiC and AIN technology, engineered for high-power industrial applications, delivering stable and efficient power conversion.
Features
- High Voltage & High Current: Rated at 1700V and 3600A for demanding operations
- Excellent Thermal Cycling: Ensures long service life and stable performance
- 10μs Short-Circuit Withstand: Provides robust system protection
- Advanced Substrate Technology: Combination of AISiC and AIN enhances heat dissipation
Applications
- Traction drive systems
- Motor control equipment
- Smart grid solutions
- High reliability inverters
Additional information
| Module | IGBT |
|---|---|
| Package | E/E2: 190×140×38 |
| Feature | TSA |
| Circuit Diagram | Single Switch |
| Blocking Voltage (V) | 1700 |
| Module Current (A) | 3600 |
