1200V 16A Silicon Carbide Schottky Diode
VRRM = 1200 V
IF (Tc=155 ℃) = 16 A
QC = 106 nC
Description
Features
- 1200V Schottky Rectifier
- Zero Reverse Recovery Current
- High-Frequency Operation
- Temperature-Independent Switching
- Extremely Fast Switching
Benefits
- Replace Bipolar with Unipolar Rectifiers
- Essentially No Switching Losses
- High Efficiency
- Reduction of Heat Sink Requirements
- Parallel Devices Without Thermal Runaway
Applications
- Switching Mode Power Supply
- Boost Diodes in PFC
- DC/DC Converters
- AC/DC Converters
- Free Wheeling Diodes in Inverter
Maximum Ratings
- Tc=25°C unless otherwise specified
Additional information
| Module | SiC SBD |
|---|---|
| Package | TO-247-3 |
| Blocking Voltage (V) | 1200 |
| Module Current (A) | 16 |
| Tjmax (℃) | 155 |
